Feature
- The N52H magnets offer superior magnetic strength, providing better torque and power delivery. This ensures smoother flight control, faster response times, and overall improved performance for FPV drones, especially in challenging conditions.
- The 12N 14P configuration with a larger 31mm x 10mm stator offers excellent torque and power efficiency. This makes it perfect for drones that require stable, powerful thrust, particularly for heavy-lift or long-range flights.
- The motor weighs just 88g (without wires), maintaining an excellent power-to-weight ratio. The Φ32mm x 40.3mm size ensures compatibility with a wide range of drone frames while minimizing the overall weight impact on the drone.
- With an internal resistance of 0.085 ohms, the motor minimizes heat generation and energy loss, ensuring efficient power transfer. This reduces strain on the motor during high-power operations, extending its lifespan and reliability.
- Tailored to FPV Flight Styles: The 900KV motor is ideal for larger loads or long-distance flights where smooth power delivery and longer flight times are critical; 1100KV motors balanced for versatile flying styles, providing both speed and torque for racing or freestyle flying.
- This motor is ideal for drones with 7-9 inch propellers, providing ample power and efficiency for a range of applications, from competitive FPV racing to freestyle and long-range exploration.
Specifications
Configuration:12N 14P
Stator Diameter: 31mm
Stator Length:10mm
Magnet: N52H
Motor Dimensions(Dia*Len): Φ32*40.3mm
Weight:88g (W/ o Wire)
3110 900KV
No.of Cells(Lipo):6S
Idle Current (10V): 1.2A
Max Continuous Current: 57A (6S)
Max Continuous Power: 1452W (6S)
Internal Resistance: 0.085
