Feature
- The N52H magnets offer superior magnetic strength, providing better torque and power delivery. This ensures smoother flight control, faster response times, and overall improved performance for FPV drones, especially in challenging conditions.
- The 12N 14P stator design, paired with a 28mm x 10mm stator, ensures high torque and reliable power output. This combination provides the ideal balance between power and efficiency, making it suitable for both racing and cinematic drone applications.
- Weighing 64g (without wires), the motor is designed to provide robust performance while keeping the overall weight minimal. This lightweight build is crucial for maintaining agility, responsiveness, and efficiency in FPV drones.
- With internal resistance as low as 0.055 ohms, the 2810 motor minimizes energy loss and heat generation, enhancing reliability and motor longevity. making these motors highly efficient even under full throttle. This translates to longer flight times and consistent performance
- Tailored to FPV Flight Styles: The 900KV motor is ideal for larger loads or long-distance flights where smooth power delivery and longer flight times are critical; 1100KV motors balanced for versatile flying styles, providing both speed and torque for racing or freestyle flying, compatible with 3-5S batteries; 1500KV motors has superior high speed performance for aggressive, high rpm flying, perfect for fast-paced track racing or agile freestyle stunts and is optimized for 3-4S setups.
- The motor’s dimensions (33.5mm x 35mm) make it compatible with a wide range of drone frames and setups. Its performance characteristics make it an excellent fit for 6-7 inch propellers, allowing it to excel in both high-speed races and smooth cinematic flights
Specifications
Magnet:N52H
Configuration:12N 14P
Stator Diameter: 28mm
Stator Length:10mm
Motor Dimensions(Dia*Len): Φ33.5*35mm
Weight:64g (W/ o Wire)
2810 900KV
No.of Cells(Lipo):6S
Idle Current (10V): 0.8A
Max Continuous Current: 43.8A (6S)
Max Continuous Power: 1095W (6S)
Internal Resistance: 0.07
2810 1100KV
No.of Cells(Lipo):3-5S
Idle Current (10V): 1.1A
Max Continuous Current: 52A (6S)
Max Continuous Power: 1300W (6S)
Internal Resistance: 0.064
2810 1500KV
No.of Cells(Lipo):3-4S
Idle Current (10V): 1.3A
Max Continuous Current: 60A
Max Continuous Power:1500W (6S)
Internal Resistance: 0.055
