Feature
- The 12N 14P configuration with a 28mm x 12mm stator provides excellent torque and smooth power delivery, ensuring stable and precise flight performance, especially under high-load conditions.
- Despite its high power output, the motor weighs just 73g (without wires), contributing to overall drone agility without compromising durability. The compact size of Φ33.5mm x 22.5mm ensures it fits easily into most drone frames.
- Robust 4mm Bearing Shaft: The 4mm bearing shaft adds to the motor’s durability, ensuring it can handle the stresses of high-speed racing and acrobatic maneuvers, providing long-lasting reliability under extreme conditions.
- Featuring low internal resistance—0.068 ohms (900KV) and 0.078 ohms (1100KV)—this motor minimizes energy loss, ensuring efficient power conversion and reduced heat generation, resulting in better performance and extended motor life.
- Tailored to FPV Flight Styles: The 900KV motor is ideal for larger loads or long-distance flights where smooth power delivery and longer flight times are critical; 1100KV motors balanced for versatile flying styles, providing both speed and torque for racing or freestyle flying.
- This motor is designed for drones using 7-8 inch propellers, making it an ideal choice for both competitive racing and cinematic FPV drones. Its power-to-weight ratio ensures quick acceleration, high speed, and excellent maneuverability.
Specifications
Configuration:12N 14P
Stator Diameter: 28mm
Stator Length:12mm
Bearing Shaft: 4mm
Motor Dimensions(Dia*Len): Φ33.5*22.5mm
Weight:73g (W/ o Wire)
2812 900KV
No.of Cells(Lipo):2-6S
Idle Current (10V): 1A
Max Continuous Current: 40A (6S)
Max Continuous Power: 950W (6S)
Internal Resistance: 0.068
2812 1100KV
No.of Cells(Lipo):2-6S
Idle Current (10V): 1.2A
Max Continuous Current: 60A (6S)
Max Continuous Power: 1480W (6S)
Internal Resistance: 0.078
