Features
- Small Size and Light Weight: Designed for portability, making it easy to carry and handle.
- Low Power Consumption: Efficient operation with a working current between 360mA and 400mA, extending battery life.
- RaceBand 40 Channel Auto-Searching: Automatically searches and finds available channels, supporting up to 40 channels, including RaceBand.
- 3.0-Inch High Brightness LCD Screen: Features a 480×320 resolution screen that provides clear and bright visuals.
Super Sensitive 5.8GHz 40CH Receiver: Built-in receiver with high sensitivity, ensuring robust signal reception, especially with RaceBand support. - Built-in High-Capacity Battery: Equipped with a 3.7V 800mAh lithium-ion polymer battery, providing reliable power and long usage times.
Universal USB Charging Interface: Allows for convenient charging through any standard USB port.
Real-Time Video Return: Ensures very low time-delay, providing immediate feedback which is crucial for applications needing prompt response. - Bilingual Menu Support: Offers menu options in both Chinese and English, enhancing usability for a broader audience.
External Video Signal Input: Supports external video sources, adding versatility to its usage.
AV Signal Output: Allows connection to an external DVR, enabling additional recording and playback options.
Specification
- Screen Size: 3 inch IPS
- Resolution: 480*320
- Frequency: 5645-5945MHz
- Receiving: 40CH Support Auto-searching
- Working Current: 360-400mA
- Built-in Battery 3.7V/1200mAh
- Charging: Micro-USB charging
- Support external video signal input
- Support AV signal output(connect external DVR)
- Product Weight: 62.5g
- Product Size: 83.5(L)*52(W)*13.3(H)mm
- Packing Size: 119*110*25mm
- Packing Weight: 165.2g
Frequency Table
