Feature
- Upgraded High-Torque Design: This brushless motor features a 12N14P configuration, delivering smooth, reliable, and powerful performance. Its high-torque design enhances stability and control.
- Wide Voltage Range Compatibility: 1300KV supports 2-6S LiPo batteries for a wide power range, perfect for long flights or heavier drone builds; 1500KV supports 3-5S batteries for a balance of power and speed; 1700KV supports 3-4S batteries, delivering fast response and acceleration for lightweight, agile drones.
- Motor KV 1300/1500/1700KV, shaft size 4 x 14mm, motor mount M3*19, which is compatible with 6-7inch propeller.
- Efficient Power Usage: Low internal resistance (as low as 00.045 ohms) ensures minimal energy loss and heat buildup, making these motors highly efficient even under full throttle. This translates to longer flight times and consistent performance
- Tailored to FPV Flight Styles: The 1300KV motor is ideal for larger loads or long-distance flights where smooth power delivery and longer flight times are critical; 1500KV motors balanced for versatile flying styles, providing both speed and torque for racing or freestyle flying, compatible with 3-5S batteries; 1700KV motors has superior high speed performance for aggressive, high rpm flying, perfect for fast-paced track racing or agile freestyle stunts and is optimized for 3-4S setups.
Specifications
Configuration:12N 14P
Stator Diameter: 28mm
Stator Length:7mm
Motor Dimensions(Dia*Len): Φ33.5*17.5mm
Weight: 48.6g；47.9g（1700KV) (W/ o Wire)
2807 1300KV
No.of Cells(Lipo): 2-6S
Idle Current (10V): 1A
Max Continuous Current:39A (6S)
Max Continuous Power: 975W (6S)
Internal Resistance: 0.06
2807 1500KV
No.of Cells(Lipo):3-5S
Idle Current (10V): 1.2A
Max Continuous Current: 47A (6S)
Max Continuous Power: 1175W (6S)
Internal Resistance: 0.055
2807 1700KV
No.of Cells(Lipo):3-4S
Idle Current (10V): 1.9A
Max Continuous Current: 42A
Max Continuous Power: 657.3W (6S)
Internal Resistance: 0.045
