Feature:
- Maximum RF power of this transmitter is 2000mW, providing ultra-high power for long-distance video transmission, ensuring strong and stable signals over long distances.
- The transmitter supports three levels of transmit power (PIT, 25mW, 2000mW), allowing users to select the appropriate power setting based on their specific needs and conditions.
- This feature enables easy adjustment of power, band and channel settings via IRC-tranp, enhancing flexibility and compatibility with betaflight.
- The VTX features side LED indicators and adjustment buttons, providing intuitive status readouts and straightforward adjustments for easy management of settings.
- Full metal casing and independent cooling fan ensure efficient heat dissipation, maintaining stable and smooth transmission even at the maximum power of 2000mW.
- This VTX operates within an output frequency range of 1060MHz to 1380MHz, providing 9 channels.
- Ultra-high output power and stable transmission performance enable the transmitter to achieve new long-range recordings, making it ideal for long-range FPV applications.
Specification:
- Input voltage: 7-36V DC; 2-8S
- Output voltage: 5V 1A
- 12V Input Current: 235mA@Pitmode, 360mA@25mW, 880mA@2000mW,
- Channel: 9CH (1060MHz-1380MHz)
- Power: PIT/25/2000/mW
- Antenna Connector: MMCX
- VTX Protocol: IRC-tramp
- Material: Aluminum
- Dimensions: 37.7*36.1*11 mm; 30.5*30.5mm (Hole)
- Weight: 16g (W/ o Antenna)
Frequency Table
Package Included
- 1 x 1.2GHz VTX
- 1x MMCX to SMA Cable
- 1x 6 Pin 1.0 Harness
- 1x 1.2G Y-Type Dedicated Antenna
